Hello,dear customers,hot-selling Eaton MTL F304 module on sale now with a cmpetitive price,100% original new and brand,send an inquiry and we will supply the best price for you.

Eaton MTL F304 product description:

F300 Megablocks are DIN-rail mounted passive hubs for Foundation™ fieldbus H1 and Profibus PA networks for general purpose, Zone 2 and Division 2 applications. They provide a simple means of connecting field devices to the network trunk cable, and protect the segment from spur short circuits. Megablocks minimize hand wiring and allow individual devices to be added to and removed from the segment without disrupting network communication. A green power LED on each unit indicates whether at least 10V dc is present. F300 Megablocks are available in four, eight, and twelve drop versions. The black Trunk In/Out pluggable connector allows replacement of a Megablock without breaking the trunk connection to other devices on the fieldbus segment. The F97 terminator supplied should be mounted in the Trunk-out connection to provide termination when the Megablock is located at the end of the fieldbus segment; alternatively, if the segment is extended, it can be removed to ensure the correct termination is maintained. Spur connections to the Megablock are made using pluggable, grey, screw-terminal or spring clamp terminal connectors. Wire terminations can be made to the individual connectors before plugging them into the Megablock. Devices can then be connected and disconnected easily during commissioning. After commissioning, retaining screws are tightened to secure each connector to the Megablock. Separate numbered connections are provided for each spur drop.
