Our New arrival Pepperl fuchs F2D0-T1-Ex8.FF.CGS.ST Temperature Multi-Input Device with Aluminum Housing product for your reference.

This fieldbus junction box holds a temperature multi-input device for transferring signals from resistance temperature measuring sensors and thermocouples, as well as resistance and millivolt signals via FOUNDATION Fieldbus H1. The fieldbus junction box with 8 inputs can be installed in Zone 1/Div. 1 with sensors located in Zone 0/Div. 1.

The housing, type F2, is made of sturdy cast aluminum for installation in rough environments. Fieldbus and field device entrances can be selected individually from a range of cable glands. Optionally, either screw terminals or spring terminals can be chosen. A tag plate is available as option.

Pepperl fuchs F2D0-T1-Ex8.FF.CGS.ST Temperature Multi-Input Device product features.

• For 8 temperature or analog sensors

• Installation in Zone 1/Div. 1, intrinsically safe

• Sensors in Zone 0/Div. 1

• Connection to fieldbus acc. to FISCO or Entity

• For FOUNDATION Fieldbus H1

• PCS integration via device description and function blocks

• Concentrator method for simplified configuration

• Monitors sensor condition

• For T/C, RTD 2-, 3-, 4-wire, voltage and resistance

• Cold junction compensation

• Removable terminals

Pepperl fuchs F2D0-T1-Ex8.FF.CGS.ST Multi-Input Device with Aluminum Housing

Pepperl fuchs F2D0-T1-Ex8.FF.CGS.SC Multi-Input Device with Aluminum Housing

Pepperl fuchs F2D0-T1-Ex8.FF.CGB.ST Multi-Input Device with Aluminum Housing

Pepperl fuchs F2D0-T1-Ex8.FF.CGB.SC Multi-Input Device with Aluminum Housing

Pepperl fuchs F2D0-T1-Ex8.FF.CG.ST Multi-Input Device with Aluminum Housing

Pepperl fuchs F2D0-T1-Ex8.FF.CG.SC Multi-Input Device with Aluminum Housing

More product picture for Pepperl fuchs F2D0-T1-Ex8.FF.CGS.ST Temperature Multi-Input Device.

We supply Germany original Pepperl fuchs F2D0-T1-Ex8.FF.CGS.ST Temperature Multi-Input Device with competitive price.

Original package for Pepperl fuchs F2D0-T1-Ex8.FF.CGS.ST Temperature Multi-Input Device here for you.

If you need more information for our Pepperl fuchs Temperature Multi-Input Device with Aluminum Housing product, please feel free to contact me here.
