High quality MTL45/46/5500 isolated safety barrier on sale now,brand new and original with a competitive price.

MTL45/46/5500 product description:

The analogue input modules, MTLx541 (single channel) and MTLx544 (dual channel) are intrinsic safety isolators that interface with process measurement transmitters located in a hazardous area of a process plant. They are also designed and assessed according to IEC 61508 for use in safety instrumented systems up to SIL3, without hardware redundancy. Each module provides a fully-floating dc supply for energising conventional 2-wire or 3-wire 4-20mA process transmitters while repeating the current flowing in the field loop into another floating circuit to drive the safe area load. The MTLx544D repeats the current flowing in a single field loop into two isolated safe area loads. For ‘smart’ 2-wire transmitters using the HART protocol the units allow bi-directional communications superimposed on the 4-20mA signal current. There are no configuration switches or operator controls to be set on the modules. These modules are members of the MTL4500 and MTL5500 range of products.

More hot sale product models for MTL4500 range barriers as below for your reference.

MTL4500 Series Barriers

Part Number

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514 (B)(D), MTL4516, MTL4516C, MTL4517, MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524, MTL4524S, MTL4525, MTL4526, MTL4531, MTL4532, MTL4533, MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4541T, MTL4544, MTL4544A, MTL4544AS, MTL4544B, MTL4544D, MTL4544S, MTL4546, MTL4546C, MTL4546S, MTL4546Y, MTL4549, MTL4549C, MTL4549Y, MTL4561, MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581

MTL4500 range

Part NumberDescription

Digital Input modules

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514, MTL4514B, MTL4516,

MTL4516C, MTL4517

Digital Output modules

MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524,

MTL4524S, MTL4525, MTL4526

Pulse and Vibration modules

MTL4531, MTL4532, MTL4533

Analogue Input modules

MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4544, MTL4544A,

MTL4544AS, MTL4544B, MTL4544D, MTL4544S

Analogue Output modules

MTL4546, MTL4546C, MTL4546Y, MTL4549, MTL4549C, MTL4549Y

Fire and Smoke Interface modules

MTL4561

Temperature Input modules

MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581

General modules

MTL4599, MTL4599N

For any related inquiry about MTL5522 barrier, you can get my contact details from our website.
