New arrival MTL4546 / MTL4546C / MTL4546Y ISOLATING DRIVER for 4–20mA HART® valve positioners with line fault detection barrier products in stock for sale at Sunup company.

MTL4546 / MTL4546C / MTL4546Y product description:

The MTLx546 accepts a 4/20mA floating signal from a safe-area controller to drive a current/pressure converter (or any other load up to 800Ω) in

a hazardous area. For HART valve positioners, the module also permits bi-directional transmission of digital communication signals. Processcontrollers with a readback facility can detect open or short circuits in the field wiring: if these occur, the current taken into the terminals dropsto a preset level. The MTL4546C and the MTLx546Y are very similar to the MTLx546 except that they provide open circuit detection only.

Good news! Here we share you the real product picture for MTL4546C barrier as below.

MTL4546C barrier back side product picture for your reference.

more hot sale product models for MTL4500 range.

MTL4500 Series Barriers

Part Number

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514 (B)(D), MTL4516, MTL4516C, MTL4517, MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524, MTL4524S, MTL4525, MTL4526, MTL4531, MTL4532, MTL4533, MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4541T, MTL4544, MTL4544A, MTL4544AS, MTL4544B, MTL4544D, MTL4544S, MTL4546, MTL4546C, MTL4546S, MTL4546Y, MTL4549, MTL4549C, MTL4549Y, MTL4561, MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581

MTL4500 range

Part NumberDescription

Digital Input modules

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514, MTL4514B, MTL4516,

MTL4516C, MTL4517

Digital Output modules

MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524,

MTL4524S, MTL4525, MTL4526

Pulse and Vibration modules

MTL4531, MTL4532, MTL4533

Analogue Input modules

MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4544, MTL4544A,

MTL4544AS, MTL4544B, MTL4544D, MTL4544S

Analogue Output modules

MTL4546, MTL4546C, MTL4546Y, MTL4549, MTL4549C, MTL4549Y

Fire and Smoke Interface modules

MTL4561

Temperature Input modules

MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581

General modules

MTL4599, MTL4599N

For any question about MTL4500 range barriers or if you want to purchase MTL4546 / MTL4546C / MTL4546Y barriers, you can feel free to send me an email.
